DMG Sprint 65 linear metal lathe
Kaiserslautern
If you decide to buy equipment at a low price, make sure that you communicate with the real seller. Find out as much information about the owner of the equipment as possible. One way of cheating is to represent yourself as a real company. In case of suspicion, inform us about this for additional control, through the feedback form.
Before you decide to make a purchase, carefully review several sales offers to understand the average cost of your chosen equipment. If the price of the offer you like is much lower than similar offers, think about it. A significant price difference may indicate hidden defects or an attempt by the seller to commit fraudulent acts.
Do not buy products which price is too different from the average price for similar equipment.
Do not give consent to dubious pledges and prepaid goods. In case of doubt, do not be afraid to clarify details, ask for additional photographs and documents for equipment, check the authenticity of documents, ask questions.
The most common type of fraud. Unfair sellers may request a certain amount of advance payment to “book” your right to purchase equipment. Thus, fraudsters can collect a large amount and disappear, no longer get in touch.
- Transfer of prepayment to the card
- Do not make an advance payment without paperwork confirming the process of transferring money, if during the communication the seller is in doubt.
- Transfer to the “Trustee” account
- Such a request should be alarming, most likely you are communicating with a fraudster.
- Transfer to a company account with a similar name
- Be careful, fraudsters may disguise themselves as well-known companies, making minor changes to the name. Do not transfer funds if the company name is in doubt.
- Substitution of own details in the invoice of a real company
- Before making a transfer, make sure that the specified details are correct, and whether they relate to the specified company.
Seller's contacts
+49 162 58...
Show
+49 162 5858448
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Location: CZ
Control Brand: FANUC
Control Model: 310
Counter Spindle: yes
Driven Tools: yes
Max. Bar Diameter: 65 mm
Control system: CNC 310 is
Total hours: 61295 h
Max. main spindle bar diameter: 65 mm
Max. counter spindle bar diameter: 45 mm
feed for main spindle max. diameter: 65mm
Main spindle power 20/25 kW
Counter spindle power 17 kW
Stroke X1 165 mm
Rapid speed X1 30 m/min
Acceleration X1 5 m/s2
Stroke Z1 678 mm
Rapid speed Z1 30 m/min
Acceleration Z1 5 m/s2
Stroke Y1 80 (+50/-30) mm
Rapid speed Y1 30 m/min
Acceleration Y1 5 m/s2
Stroke X2 165 mm
Rapid speed X2 30 m/min
Acceleration X2 5 m/s2
Stroke Z2 640 mm
Rapid speed Z2 30 m/min
Acceleration Z2 5 m/s2
Stroke W2 690 mm
Rapid speed W2 30 m/min
Acceleration W2 5 m/s2
Number of turrets 2
Number of rotating tools each station 12 all driven positions
Tool system VDI 30
Max driven tool speed 4.000 rpm
Approx. coolant tank capacity 650 l
Coolant pump max.capacity (per each turret) 20 l/min
Pump pressure 7 bar
Power supply 91 kVA
LxWxH of the machine 4.500x1.990x2.300 mm
Approx. machine weight 9.500 kg
IEMCA MASTER 865 MP 43 L bar feeder
Base machine configuration
Drive for slide 1 and 2 (all 12 pos.)
C-axis for main and counter spindle
Y-axis for slide 1
Swarf conveyor belt type
Counterspindle collet cleaning with coolant
Workpiece unloading including belt
Mechanical preparation for oil mist filter
Electrical and software interface for bar loader
Angular synchronism between main and counter spindle
Automatic machine shut down
2 additional on/off outputs (4 M-functions)
Rigid tapping
Piece and time counter
Software for polygonal turning for slide 1 and 2
Constant cutting speed
Helical interpolation for slide 1
Spindle speed control
Quadruple warning light
Cooling device for electrical cabinet
Added options
I-V50011 Collet chuck Type "MPF 65/140" without axial
Clamping elements and other equipment
I-V50025 Manual collet changer
type "SACO MPT65/140 and MPF65/140"
I-V50092 Differential pressure for counterspindle
possibility of setting two different clamping pressures
I-V50083 1 set of soft jaws for chuck
type "SMW 175-BBD"
I-V50080 Chuck type "SMW 175-BBD"
For counter spindle
including adapter for adapting the spindle
Control system options
I-V12060 Tool wear monitoring system
Monitor for CNC FANUC
I-V12070 Sister tool selection system for Tool
Monitor for CNC FANUC
Hydraulic and filtration equipment
I-V40045 External flushing of jaws/collets with coolant
on main spindle and counter spindle
Various new spare parts are included
